Tunnel washer for gears is designed to meet the strict cleanliness standards required for modern automotive gears. Since the performance and service life of a vehicle are closely tied to gear quality, any residual oil, machining debris, or dust must be thoroughly removed after processing.
Tunnel washer uses high-temperature, high-pressure steam to clean gear surfaces, efficiently eliminating oil stains, iron chips, and other contaminants, ensuring they consistently meet the required cleanliness levels before final packaging.
| Machine dimensions | 12700×2420×1920mm |
| Conveying speed | 0.5-2m/min (variable speed control) |
| Cleaning efficiency | 300-400pcs/hour |
| Water consumption | 500L/h |
| Total power | 183kW (full heating), 54kW (no heating) |
| Power supply | 380V±10%, three-phase five-wire, 50Hz |
| Water pressure | 0.3-0.5MPa (tap water) |
| Number of operators | 2 persons |
| Continuous operation | 24 hours continuous running |
We’re happy to answer your questions. Send us your request and we’ll contact you soon.
Tunnel washer for gears employs high-pressure three-stage spray system and stepped cascade water tank design, achieving > 99% oil removal efficiency. Its cleaning performance surpasses traditional equipment, ensuring high-precision gear components meet aerospace-grade standards and eliminating impurities that could compromise operational reliability.
